.Mechanical-Data-v2.2

Customer Documentation: Neonode® Touch Sensor Module User's Guide : .Mechanical Data v2.2

Physical Dimensions and Position of OriginTop View

Dimensions C and D vary between the Touch Sensor Module types (0° and 90°) and therefore also the Touch Active Area (TAA) sizes (A and B). For Touch Sensor Module types with A ? 237.6 mm, dimension B also depends on the installed firmware version.

Product number	Measurements (mm)
0°	90°	A	B	C	D
NNAMC0430PC01	NNAMC0431PC01	43.2	14.9	47.2	2
NNAMC0500PC01	NNAMC0501PC01	50.4	29.8	55.9	3.5
NNAMC0580PC01	NNAMC0581PC01	57.6	29.8	61.6	2
NNAMC0640PC01	NNAMC0641PC01	64.8	44.7	70.3	3.5
NNAMC0720PC01	NNAMC0721PC01	72	44.7	76	2
NNAMC0790PC01	NNAMC0791PC01	79.2	59.6	84.7	3.5
NNAMC0860PC01	NNAMC0861PC01	86.4	59.6	90.4	2
NNAMC0940PC01	NNAMC0941PC01	93.6	74.5	99.1	3.5
NNAMC1010PC01	NNAMC1011PC01	100.8	74.5	104.8	2
NNAMC1080PC01	NNAMC1081PC01	108	89.4	113.5	3.5
NNAMC1150PC01	NNAMC1151PC01	115.2	89.4	119.2	2
NNAMC1220PC01	NNAMC1221PC01	122.4	104.3	127.9	3.5
NNAMC1300PC01	NNAMC1301PC01	129.6	104.3	133.6	2
NNAMC1370PC01	NNAMC1371PC01	136.8	119.2	142.3	3.5
NNAMC1440PC01	NNAMC1441PC01	144	119.2	148	2
NNAMC1510PC01	NNAMC1511PC01	151.2	134.0	156.7	3.5
NNAMC1580PC01	NNAMC1581PC01	158.4	134.0	162.4	2
NNAMC1660PC01	NNAMC1661PC01	165.6	148.9	171.1	3.5
NNAMC1730PC01	NNAMC1731PC01	172.8	148.9	176.8	2
NNAMC1800PC01	NNAMC1801PC01	180	163.8	185.5	3.5
NNAMC1870PC01	NNAMC1871PC01	187.2	163.8	191.2	2
NNAMC1940PC01	NNAMC1941PC01	194.4	178.7	199.9	3.5
NNAMC2020PC01	NNAMC2021PC01	201.6	178.7	205.6	2
NNAMC2090PC01	NNAMC2091PC01	208.8	193.6	214.3	3.5
NNAMC2160PC01	NNAMC2161PC01	216	193.6	220	2
NNAMC2230PC01	NNAMC2231PC01	223.2	208.5	228.7	3.5
NNAMC2300PC01	NNAMC2301PC01	230.4	208.5	234.4	2

Product number	Measurements, Non-Extended Range (mm)		Measurements, Extended Range (mm)
0°	90°	A	B	C	D	From Firmware Version	A	B	C	D	From Firmware Version
NNAMC2380PC01	NNAMC2381PC01	237.6	208.5	243.1	3.5	v1.38	237.6	Available on request	243.1	3.5	TBA
NNAMC2450PC01	NNAMC2451PC01	244.8	208.5	248.8	2	v1.38	244.8	Available on request	248.8	2	TBA
NNAMC2520PC01	NNAMC2521PC01	252	208.5	257.5	3.5	v1.38	252	Available on request	257.5	3.5	TBA
NNAMC2590PC01	NNAMC2591PC01	259.2	208.5	263.2	2	v1.38	259.2	Available on request	263.2	2	TBA
NNAMC2660PC01	NNAMC2661PC01	266.4	208.5	271.9	3.5	v1.38	266.4	Available on request	271.9	3.5	TBA
NNAMC2740PC01	NNAMC2741PC01	273.6	208.5	277.6	2	v1.38	273.6	Available on request	277.6	2	TBA
NNAMC2810PC01	NNAMC2811PC01	280.8	208.5	286.3	3.5	v1.38	280.8	Available on request	286.3	3.5	TBA
NNAMC2880PC01	NNAMC2881PC01	288	208.5	292	2	v1.38	288	Available on request	292	2	TBA
NNAMC2950PC01	NNAMC2951PC01	295.2	208.5	300.7	3.5	v1.38	295.2	Available on request	300.7	3.5	TBA
NNAMC3020PC01	NNAMC3021PC01	302.4	208.5	306.4	2	v1.38	302.4	Available on request	306.4	2	TBA
NNAMC3100PC01	NNAMC3101PC01	309.6	208.5	315.1	3.5	v1.38	309.6	Available on request	315.1	3.5	TBA
NNAMC3170PC01	NNAMC3171PC01	316.8	208.5	320.8	2	v1.38	316.8	Available on request	320.8	2	TBA
NNAMC3240PC01	NNAMC3241PC01	324	208.5	329.5	3.5	v1.38	324	Available on request	329.5	3.5	TBA
NNAMC3310PC01	NNAMC3311PC01	331.2	208.5	335.2	2	v1.38	331.2	Available on request	335.2	2	TBA
NNAMC3380PC01	NNAMC3381PC01	338.4	208.5	343.9	3.5	v1.38	338.4	Available on request	343.9	3.5	TBA
NNAMC3460PC01	NNAMC3461PC01	345.6	208.5	349.6	2	v1.38	345.6	327.7	349.6	2	v1.49

Side View

These measurements are identical for all sensor module's lenghts but vary some between the 0° and 90 ° types. The position of origin is marked with "zero software".

0° Type
